Plans & Boundary Analysis

We provide accurate, scaled property plans and Land Registry compliant plans to support purchases, valuations and legal matters across the East Midlands.

All work is prepared by RICS-accredited surveyors, ensuring drawings are not just technically correct, but informed by a full understanding of property, value and risk. Unlike standard draughting services, our plans are designed to be relied upon for professional and legal purposes.

Land Registry Compliant Plans

We prepare plans suitable for Land Registry applications, including:

• Title plans

• Lease plans

• Transfer plans (TP1)

• Plans for first registration

• Boundary clarification plans

All plans are produced to the appropriate standards and can be tailored to solicitor or Land Registry requirements.

Boundary Analysis & Mapping

We provide clear, professional mapping to help interpret property boundaries and land ownership.

This may include:

• Overlaying title plans with Ordnance Survey mapping

• Comparison with historical plans and aerial imagery

• Identification of inconsistencies or uncertainties

• Plans to support legal advice or neighbour discussions

This service is often used to support solicitors or to provide clarity before issues escalate.

Measured Surveys & Existing Layout Plans

We undertake measured surveys of residential and mixed-use property, producing accurate plans suitable for:

• Property purchase and due diligence

• Valuation and reporting

• Refurbishment planning

• Larger or complex properties where accuracy is essential

Plans are produced using professional CAD software to ensure clarity and precision.

We are RICS-accredited

We regularly prepare Land Registry compliant plans, title plans and boundary surveys across the East Midlands, including Nottinghamshire and Derbyshire. Whether you require a plan for a transfer (TP1), lease or boundary clarification, we can be provide a clear and professional service.
